Different Security Protocols that Secures your Data Integrity

Security Protocols naming cryptographic or encryption protocols help protect sensitive data, financial data, and file transfer using the cryptographic method.

The protocol shows how the algorithm works and gives details like data structure, and data representation.

Security protocols can apply secure multi-party computation, secret sharing process, entity authentication, Non-repudiation method, and encryption method.

Such protocols ensure the data delivery in a secure way between two ends.

clickssl promotional blog banner

Below we have discussed few security protocols to protect online information.


SSL and TLS are separate protocols; however, TLS is a successor version of SSL. After SSL v3.0, TLS came into focus, and at present, TLS 1.3 is in practice by certificate authorities. Still, we know the TLS protocol with an SSL certificate.

1. SSL Protocol:

SSL protocol (Secure Socket Layer) offers data encryption, integrity, and authentication that flows between the server and the client. The protocol offers server and client authentication.

During SSL handshake to create a secure connection, session keys (public and private key) are swapped, and algorithms are agreed upon.

SSL certificates signed by a certificate authority should be compatible with almost all servers, operating systems, and browsers to avoid SSL warnings.

2. TLS Protocol:

TLS (Transport Layer Security) 1.1 was released in 2006 after two years in 2008, TLS 1.2 replaced it.

However, TLS 1.3 is used by many certificate authorities and came into play in 2018. Foremost browser authorities and search engines have already started to use TLS 1.2 and TLS 1.3 from January 2020


VPN (Virtual Private Network) creates a secure and private network while hiding an IP address to cover actual identity. VPN offers an encrypted connection, which is strong compared to a secure Wi-Fi hotspot. While surfing on insecure Wi-Fi, an attacker can steal login credentials and other private information. In that case, you need a VPN that keeps your connection anonymous. VPN offers the freedom to access a website and app in a secure environment using a secure tunnel between a local network and an exit point in another location.

Recommended: VPN Security Flaws And Its Prevention


SFTP (Secure File Transfer Protocol) is an upgraded version of FTP (File Transfer Protocol) in which the files were transferred in an unencrypted manner. SFTP removes this issue and offers a secure environment for file transfer on both local and remote servers. SFTP uses a secure SSH protocol to establish a connection. SFTP helps to protect against MiTM and password sniffing attacks. With cryptographic hash function and data encryption, SSH protects data integrity.


SSH (Secure Shell) is a cryptographic protocol for carrying out network services in a secured environment over an insecure network. Over SSH protocol, each command, file transfer, and output are encrypted to protect against network attacks. It connects a client-server application to an SSH server. SSH works on TCP port#22 and generally used on Unix and Windows systems.

Recommended: SSH Vs. SSL- What are the differences and similarities


Open Shortest Path First (OSPF) is a routing protocol that creates a route between the origin and the target router. The IETF (Internet Engineering Task Force) has developed OSPF protocol as an interior gateway protocol. It works on port 89 as a network layer protocol.


Firewall is a renowned technology that is used to protect online information. In E-commerce, firewall is used to protect E-commerce components such as Internet Payment Gateway, Server Based Wallet, and Payment Server.

Most firewalls can be divided into three categories:

  • Packet filter (without memory);
  • Filter circuit level;
  • Application-layer filters.

Packet filtering blocks or passes data packets as they pass through a network interface,which include IP-address and port numbers and destination.This type of firewall is the easiest to implement and maintain, and almost no effect on network performance but its protection level is very low.

Filter Circuit level is an intermediate between the packet filter and application layer. Filter circuit-level monitors handshake (handshake) between the authorized client and the external host that determines whether the requested session is valid.Information delivered to a remote computer over a circuit level gateway seems to have originated from the gateway; such it hides the information on protected networks. Such circuit level is inexpensive and suitable for protecting private network. It does not filter individual packets.

Application-level filters provide a high degree of protection, but it is expensive and can increase complexity. Such filters are implemented as a dedicated firewall. The server application is located on a private network behind a firewall. In fact, the client cannot find the application proxy (proxy application server) with the firewall. In contrast to the filter circuit level, application-level intermediaries allow only packets that they were assigned to work. Application-level intermediaries check the contents of each packet passing through the gateway.


It encrypts data at the network level that consists of three protocols: Authentication Header, Encapsulating Secure Payload (ESP), and Internet Key Exchange (IKE).

  • The Authentication Header provides data origin authentication, data integrity, and protection from the burden of repeated messages. The AH protocol authenticates every packet, which makes ineffective the program, and tries to seize control of the session.
  • ESP offers validation and integrity for the payload and not for the IP header.ESP protocol provides encryption of data streams. It uses SHA and MD5 standard algorithms.
  • IKE protocol solves the problem of key distribution protocol based on Diffie-Hellman. It establishes security association (SA) in the IPsec. It uses DNS and a Diffie-Hellman key exchange to establish a shared secret session.

IPSec has spread in two main configurations. First configuration carries Network Layer Protocol that uses for data transfer between gateways for local networks that support IPv4 for unencrypted transmission of network. Second configuration is for closing the data within the network, for that all the jobs and the web server must support the protocol IPSec. Today, most modern operating systems (Windows 2000, Linux, and Solaris) protocol supports IPSec.


If we talk about PCT (Private Communication Technology), it works same as SSL. The main difference between PCT and SSL is the message size. PCT has a smaller set of message compared to SSL.PCT supports algorithms RSA, Diffie-Hellman, Fortezza key management; DES, RC2 and RC4 – data encryption; DSA and RSA – for digital signature.PCT is implemented in Microsoft Internet Explorer version 3 and above, as well as Microsoft Internet Information Server version 2 and above. PCT has more options in the negotiation of an algorithm and data formats. While authenticating and encrypting the message, it requires two separate key in PCT. However, in SSL both need a single key.

As you can see

There are emerging risks for online threats and server vulnerability that can damage your network or can steal your data. Either firewall, HTTPS, or IPSec warn about possible violations of security. However, PCT has been replaced by SSLv3 and TLS (Transport Layer Security). Today if we see, SSLv3 is the best security used for server, network, and browser security and many organizations, institutes and corporate have started to adopt SSL technology. Even social media and giant search engines have taken a step in the direction of protecting their business with SSL.
